2901 0566 22 is a special oil-gas separation Filter Element (oil separation core) for Atlas air compressor. It is a core consumable for screw air compressor maintenance and has the following characteristics:

Core Features

High precision filtering

Using glass fiber filter material with a filtration accuracy of 0.1 μ m, it can intercept tiny oil droplets in compressed air, reducing the oil content in the output air to below 3ppm

The filtration efficiency is as high as 99.99%, and oil mist is separated through interception, diffusion, and polymerization

Strong adaptability

Specially designed for Atlas screw air compressor (such as GA series), compatible with model 1622365600

Suitable for industrial compressor maintenance and repair, ensuring long-term stable operation of equipment

Long lasting and durable

The service life is approximately 3500-5200 hours, depending on the operating conditions

The initial pressure difference is ≤ 0.02MPa, and it is recommended to replace the pressure difference with 0.7MPa. Regular monitoring of pressure difference changes is required

Craftsmanship and Materials

The sealing material meets industrial standards to ensure the effectiveness of oil and gas separation
