The 0950R005ON hydraulic oil Filter Element is a foldable filter element mainly made of glass fiber and stainless steel, with a filtration accuracy of 5 μ m, a maximum working pressure of 300 bar, and a working temperature ranging from -10 to 110 ℃. It can effectively filter out solid particles and gel like substances in hydraulic oil and is commonly used in hydraulic systems such as power plants and steel lubrication stations. It has the characteristics of high filtration efficiency, low pressure loss, and high structural strength.

The characteristics of the 0950R005ON hydraulic Oil Filter Element are as follows:

High filtration efficiency: using glass fiber filter material, with a filtration accuracy of 5 microns and a filtration ratio grade of ≥ 1000, it can efficiently filter out metal particles, pollutants and impurities in hydraulic oil, protecting the normal operation of hydraulic equipment.

Low pressure loss: Equipped with Helios special pleated structure and outer layer wrapped with perforated design, it can optimize fluid flow, evenly disperse liquid flow stress, reduce turbulence between pleats, and thus reduce pressure drop.

High structural strength: The end cap and center tube are made of corrosion-resistant steel, which complies with relevant standards such as ISO 2941 anti collapse and anti explosion, ISO 3724 flow fatigue characteristics, etc. The anti collapse pressure reaches 150psid and can withstand complex working conditions of hydraulic systems.

Good conductivity: Some models use conductive plastics and other materials to release static electricity, avoiding the accumulation of static electricity and sparking, thereby avoiding risks such as oil carbonization and accumulation, and ensuring reliable operation.

Reliable sealing: By using nitrile rubber (NBR) seals, the sealing effect can be ensured, preventing unfiltered oil from entering downstream hydraulic components.

Easy to maintain: With a simple structure, small size, and light weight, it meets the standard flow fatigue characteristics and can be easily disassembled, cleaned, or replaced as needed.
